SSU_EN
| Código EAN | 8595568938084 |
| Elcodigo aduanero | 73269098 |
| Peso | 0,0991 kg/pcs |
| Tratamiento superficial | Magnelis® |
| Resistencia térmica | -50 - 150 °C |
| Corresponde a las normas | ČSN EN 61537 |
| Espesor de la chapa metálica | 1,5 mm |
| Cantidad de tornillos para la conexión | 4 |
| Dimensión H | 50 mm |
| Para la altura de la bandeja | 60 mm |
Angle couplings are used to create any angle, mainly for connecting in places of a slight bend in the route or for creating arcs of large radii or bypassing columns and pillars. The connection is performed using the bolts NSM 6X10. These items can also be ordered in a varnished version.
